Assembly
8
STEP 3
Slide the Adjustable Frame (3) into the tube of
the Main Frame (4). Set your desired height
using the Black Ball Pen (12) and secure in place
with the Knob Bolt 3/4” (14). (Figure 3)
Step 4
Insert the Foam Rod (9) through the holes at the
bottom of the Adjustable Frame (3). Use one Hex
Bolt M6*48mm (33), two Washers M6 (37), and
one Locknut M6 (39) to secure the rod in place.
Next, place one of the Roller Pads (40) into a
Foot Foam Brackets (10) and slide one onto each
end of the Foam Rod (9). Make sure the holes of
both the Foot Foam Bracket (10) and the Roller
Pads (40) line up together. Insert the Foot Frame
(6) into the Adjustable Frame (3) and secure in
place using Knob Bolt M8 (15). (Figure 4)
Figure 3
Figure 4
