GRAPHICS COMMANDS
Print normal-density 8-bit graphics
I I I Hexadecimal I
Both
<ESC> “K” nl n2
27 75 nl n2 IB 4B nl n2
ml m2
ml m2 ml m2
Prints bit-image graphics at 60 dots per inch horizontally. The graphic image is48
dots high and
nl +n2 x 256dots wide. Maximum width is 8 inches (480 dots).
ml, m2, ... are the dot data, each a l-byte value from O to 255 representing 48
vertical dots, with themost significantbitat thetop sixdots andthe least significant
bit at the bottom six dots.
The number of data bytes must be
rd +n2x 256.Dots beyond the right margin are
ignored.
At the end of bit-image printing the printer returns automatically to character
mode.
Print double-density 8-bit graphics
<ESC>“L” nl n2
27 76 nl n2 IB 4C nl n2
ml m2
ml m2 ml m2
<ESC> “Y” nl n2 27 89 nl n2
IB 59 nl n2
ml m2
Prints bit-image graphics at 120 dots per inch horizontally (maximum 960 dots
wide).
See <ESC> “K” for other information.
Print quadruple-density 8-bit graphics
~ I I I Hexadecimal I
I I
<ESC> “Z” nl n2
Both
I
27 90 nl n2
I
IB 5A nl n2
ml m2 ml m2
ml m2 .,.
I
Prints bit-image graphics at 240 dots per inch horizontally (maximum 1920dots
wide), skipping every second dot in the horizontal direction. See <ESC> “K” for
other information.
Chapter6 PRINTER CONTROL COMMANDS 57
