— 64 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
A
COMMON PARTS LISTING
D501 8-719-945-80 DIODE ERC06-15S
D502 8-719-908-03 DIODE GP08D
D503 8-719-908-03 DIODE GP08D
D520 8-719-067-63 DIODE MDV04-600
D521 8-719-302-43 DIODE EL1Z
D522 8-719-991-33 DIODE 1SS133T-77
D523 8-719-991-33 DIODE 1SS133T-77
D541 8-719-908-03 DIODE GP08D
D550 8-719-110-08 DIODE RD8.2ESB2
D552 8-719-302-43 DIODE EL1Z
D561 8-719-979-85 DIODE EGP20G
D562 8-719-979-85 DIODE EGP20G
D571 8-719-991-33 DIODE 1SS133T-77
D572 8-719-991-33 DIODE 1SS133T-77
D573 8-719-110-08 DIODE RD8.2ESB2
D574 ¡ 8-719-302-43 DIODE EL1Z
D581 8-719-991-33 DIODE 1SS133T-77
D601 8-719-510-51 DIODE D3SB60F
D602 8-719-991-33 DIODE 1SS133T-77
D604 8-719-060-90 DIODE S2L60F
D605 8-719-060-90 DIODE S2L60F
D610 ¡ 8-719-057-52 DIODE EZ0150AV1
D615 8-719-510-12 DIODE D10SC4M
D618 8-719-022-97 DIODE D2S4MF
D620 8-719-022-97 DIODE D2S4MF
D621 8-719-052-90 DIODE D1NL40-TA2
D622 8-719-052-90 DIODE D1NL40-TA2
D650 8-719-109-89 DIODE RD5.6ESB2
D670 8-719-991-33 DIODE 1SS133T-77
D690 8-719-991-33 DIODE 1SS133T-77
D691 8-719-991-33 DIODE 1SS133T-77
FERRITE BEAD
FB350 VARIANT (SEE VARIANT PARTS LIST)
FB501 1-410-396-41 FERRITE
FB521 1-410-397-21 FERRITE 1.1UH
FB522 1-410-397-21 FERRITE 1.1UH
FB601 1-410-396-41 FERRITE
FB602 1-410-396-41 FERRITE
FB603 1-412-911-11 FERRITE
FB605 1-412-911-11 FERRITE
IC
IC001 8-759-496-18 IC M37273MF-XXXSP
IC002 8-759-371-21 IC MM1319AFBE
IC003 8-759-353-44 IC ST24C08FM6TR
IC010 VARIANT (SEE VARIANT PARTS LIST)
IC202 8-759-100-96 IC UPC4558G2
IC203 8-759-534-81 IC MM1313AD/
IC301 VARIANT (SEE VARIANT PARTS LIST)
IC302 VARIANT (SEE VARIANT PARTS LIST)
IC401 VARIANT (SEE VARIANT PARTS LIST)
IC402 8-752-072-39 IC CXA2021S
IC521 ¡ 8-759-700-07 IC NJM2903M
IC541 8-759-980-58 IC TDA8172
IC601 ¡ 8-729-039-65 TRANSISTOR MX0541B-F
IC603 ¡ 8-749-012-13 IC DM-58
IC604 8-759-198-03 IC PQ09RF21
JACK
J200 1-774-750-21 JACK BLOCK, PIN 2P
J201 1-774-751-11 TERMINAL BLOCK, S
J202 VARIANT (SEE VARIANT PARTS LIST)
J204 1-774-749-11 JACK BLOCK, PIN
CHIP CONDUCTOR
JR001 1-216-295-91 SHORT
JR003 1-216-295-91 SHORT
COIL
L001 1-410-470-11 INDUCTOR 10UH
L002 1-412-032-11 INDUCTOR CHIP 100UH
L003 1-412-032-11 INDUCTOR CHIP 100UH
L101 1-412-029-11 INDUCTOR CHIP 10UH
L150 1-412-032-11 INDUCTOR CHIP 100UH
L151 1-412-029-11 INDUCTOR CHIP 10UH
L301 1-412-031-11 INDUCTOR CHIP 47UH
L302 1-412-029-11 INDUCTOR CHIP 10UH
L350 VARIANT (SEE VARIANT PARTS LIST)
L351 VARIANT (SEE VARIANT PARTS LIST)
L501 ¡ 1-411-976-11 COIL, HORIZONTAL LINEARITY
L502 1-412-552-11 INDUCTOR 2.2MMH
L503 1-406-677-11 INDUCTOR
L504 1-412-533-21 INDUCTOR 47UH
L520 1-409-955-11 INDUCTOR
L591 ¡ 1-412-528-61 INDUCTOR 18UH
L601 1-216-389-11 METAL OXIDE 1 5% 3W F
IC LINK
PS201 1-532-984-11 LINK, IC 2A/90V
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡
) are critical for
safety. Replace only with
part number specified.
Note:
Les composants identifies per
un trame et une marque
¡¡
¡¡
¡ sont
critiques pout la securite. Ne les
remplacer que par une piece
portant le numero specifie.
2.1 BA4#3 (COM) (BASE) w/var 6/8/98, 4:20 PM64
