REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 58 —
KV-27V40 / 27V45 / 27V65 / 29VL40 / 29VL65A / 29VL65C / 29VL85 / 29VL95
7-3. MAIN POWER SWITCH (KV-29VL65A ONLY)
100 * A-148-056-A BLOCK ASSY, HZ 101-103
101 * 4-048-201-21 BRACKET, PC BOARD HZ
102 * 4-048-200-21 BUTTON, MAIN POWER
103 * A-1372-117-A MOUNTED PCB, HZ
• Items marked "
*
" are not stocked
since they are seldom required for routine
service. Some delay should be
anticipated when ordering these items.
• Items with no part number and no
description are not stocked because
they are seldom required for routine service
The components identified with gray shading and a critical
symbol (
¡¡
¡¡
¡
) are critical for safety. Replace only with part
number specified.
Note:
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pout la securite. Ne les remplacer que
par une piece portant le numero specifie.
Note:
• The component parts of an assembly
are indicated by the reference numbers in
the remarks column.
REF.NO. PART NO. DESCRIPTION REMARK
101
102
100
103
