Other Information
28
Preparation for Wall Mounting
This TV can be installed on a wall by using a wall-mount bracket (sold
separately). Before mounting the TV on a wall, the Table-Top Stand must be
removed from the TV.
Follow the simple steps below to remove the Table-Top Stand:
1 Disconnect all the cables from the TV.
2 Cover a level and stable surface with a thick and soft cloth.
3 Gently lay the TV, face down, onto the cloth. Make sure the Table-Top
Stand is hanging over the edge.
4 Pull the cable band out completely.
5 Remove the four screws.
Detach the Table-Top Stand from the TV.
6 Do not remove any other screws from the TV.
Do not remove the Table-Top Stand for any reason other than to wall-
mount the TV.
Cable band
Table-Top Stand Soft cloth
Sony Wall-Mount
Bracket Model
SU-WL100
