Basic Operations
19
Basic Operations
TV Controls
INPUT
MENU
POWER
CHANNEL
PIC OFF/TIMER
POWER
9
876
VOLUME
Item Description
1 MENU Press to display the TV functions and settings (See “Using the Menus” on page 20).
2 INPUT Press to display the inputs list. The Inputs feature lets you select the TV and the external
inputs connected to your TV. You can also assign a label using Label Video Inputs in the
Setup settings (see page 23).
In the TV settings screen, this button is used to confirm the selection or setting.
3 – VOLUME + Press to adjust the volume. In the TV settings screen, these buttons serve as left/right buttons.
4 – CHANNEL + Press to scan through channels. To scan quickly through channels, press and hold down either
–/+. In the TV settings screen, these buttons serve as up/down buttons.
5 POWER Press to turn on and off the TV.
6 PIC OFF/
TIMER LED
Lights up in green when the Picture Off feature is activated. Lights up in orange when Sleep
Timer is set. For details, see page 23.
7 POWER LED Lights up in green when the TV is turned on.
8 (IR) Infrared
Receiver
Receives IR signals from the remote control. Do not put anything near the sensor, as its
function may be affected.
9 Speaker Outputs audio signal.
The CHANNEL + button has a tactile dot. Use it as a reference when operating the TV.
Make sure that the TV is turned off before unplugging the power cord. Unplugging the
power cord while the TV is turned on may cause the TV to malfunction.
