User’s Reference Manual: Display Console 11
Keypad
Use the keypad to enter your workout session selections. Keys on the
keypad respond to the slightest touch. Use gentle pressure on the
keys as you exercise.
INCLINE ▲▼: Press and hold the INCLINE arrow keys to
increase or decrease the incline from 0% to 15% in 0.5%
increments.
During your workout, to view your current incline, tap either
INCLINE ▲ or ▼ key. To change the incline, press the arrow
key for more than one second.
Changes to the incline are not immediate. It takes time for the
lift to reach the target incline shown on the display.
The incline setting affects the column height in the program
profile as shown in Diagram 4.
The height of the column indicates the level of incline. Every
time the incline changes by four sequential levels (up or down)
the height of the column changes by one row. The top row
lights when inclines are 12% or above.
Diagram 4: Column height affected by changes in incline
Note: During the setup phase, pressing the INCLINE arrow
keys will not affect the incline. However, the arrow keys do
affect what appears on the display. Refer to Selecting a
Program.
RESET: During pause mode, press the RESET key to display a
WORKOUT SUMMARY. Press RESET again to return to the
Precor banner. No workout statistics are saved.
QUICKSTART: Press QUICKSTART to bypass the setup
prompts and start your workout immediately using the Manual
Program. Refer to Choosing QUICKSTART.
STOP
0 – 1.5
2 – 3.5
4 – 5.5
6 – 7.5
8 – 9.5
10 – 11.5
12 – 15
Column height
Incline Setting
