ENGLISH
________________________
11.7 Connect a DVD player
with a S-VIDEO connector
ç When using the S-VIDEO connector,do not connect any device to
the
AV VIDEO input that you are usting.
________________________
11.8 Connect a recorder and Set top box
with RF output
___________________
11.9 Connect a satellite receiver or Set top box
with A/V outputs
If your device has an S-VHS video jack: For improved picture quality,
connect a S-video cable with the
S-VIDEO input of AV1 and connect
the audio cables to the
AUDIO L and R input jacks of AV1.
ç When using the
S-VIDEO connector do not connect any device to
the
AV1 video jack.
In case of mono equipment, only the left loudspeaker reproduces sound.
Use a mono to stereo adapter (not supplied) for sound reproduction via
all internal loudspeakers.
________________________
11.10 Connect a satellite receiver or Set top box
and a recorder with A/V outputs
If your device has an S-VHS video jack: For improved picture quality,
connect a S-video cable with the
S-VIDEO input of AV1 and connect
the audio cables to the
AUDIO L and R input jacks of AV1.
ç When using the
S-VIDEO connector do not connect any device to
the
AV1 video jack.
In case of mono equipment, only the left loudspeaker reproduces sound.
Use a mono to stereo adapter (not supplied) for sound reproduction via
all internal loudspeakers.
________________________
11.11 Connect digital source devices
with Component Video Output connectors (YPbPr)
This TV is capable of displaying 1080i,1080p, 720p and 480p DTV signals
when connected to a DTV tuner cable box. Select the output of the
cable box to either 1080i, 1080p, 720p or 480p. A DTV signal must be
available in your area.
________________________
11.11.1 With
DIGITAL AUDIO
27
