ASSEMBLY
OM 0370SB1388-A 20
Installation of Snowblower with Three Point Hitch
(Figure 17)
1. Attach tractor lower hitch arms (item 1) to
snowblower lower hitches (item 7) using the
hitch pins and linchpins (items 6-2).
2. Install the tractor adjustable arm (item 3) on the
upper or lower hole of the snowblower
attaching plates (item 5) using the tractor pins
(item 4).
3. To level the snowblower front to back, adjust
using the tractor adjustable arm (item 3).
4. To level side to side, use the leveling crank on
right lower lift arm.
5. Set the tractor anti-sway turnbuckles so the
snowblower does not sway. Be sure the
turnbuckles clear the tractor tires.
CAUTION
Before connecting snowblower driveline to
tractor drive shaft, make sure driveline is not
too long in raised, lowered and middle
position. If the driveline is too long it must be
shortened, to avoid damaged to tractor. See
pages 22 to 25 for instructions.
6. Connect driveline to tractor drive P.T.O., make
sure that the driveline in is properly engaged.
Figure 17
