Configuring PAD/ATPAD Ports 3
Typical Applications
Typical Applications
Introduction
You can access the PAD with PC scripts. The PC scripts use AT commands to make
calls through an X.25 network.
Example
Figure 1 shows the use of modems in an application. It also shows how the
PathBuilder S200 series switch with the PAD port replaces the modems and
concentrates mixed data types on a single access line. A PC runs purchased script
files that use AT commands.
Figure 1. Topologies with and Without the PAD
Before PAD
PC
AT Modem
Other Devices
Other Dedicated Modems/Lines
Single Access Line
Network
With PAD
PC
Other Devices
Access
Product
