PART LIST—Model No. 831.285270 R0601A
Note: “#” indicates a non-illustrated part. “
*
” indicates that an extra part may be included. Specifications are
subject to change without notice. See the back cover of this manual for information about ordering replacement
parts.
Key
No. Qty. Description
1 1 Frame
2 1 Pivot Axle
3 1 Upright
4 1 Right Side Shield
5 1 Left Side Shield
6 1 Console
7 2 Foam Handlebar Grip
8 2 Handlebar
9 6 M4 x 19mm Flange Screw
10 1 T-handle
11 8 Pedal Arm Bushing
12 2 Pedal Arm
13 10 M5 x 16mm Button Screw
14 1 Resistance Strap
15 1 Strap Buckle
16 11 M4 x 16mm Screw
17 2 M6 Nut
18 2 Adjustment Bracket
19 2 Eyebolt
20 2 M8 Nylon Jam Nut
21 1 Flywheel Axle
22 2 Flywheel Bearing
23 1 Flywheel
24 1 Magnet
25 1 Reed Switch/Wire
26 1 Resistance Control/Cable
27 2 Rear Stabilizer Endcap
28 1 Tension Spring
29 6 M10 Nylon Locknut
30 1 Belt
31 1 Left Pedal
32 1 Pulley w/Shaft
33 1 Rear Stabilizer
34 1 Front Stabilizer
35 2 5/16” Zinc Bolt
Key
No. Qty. Description
36 2 Pulley Bearing
37 2 Pedal Disk
38 2 M6 Split Washer
39 2 Nylon Spacer
40 1 Side Shield Bracket
41 2* Pedal Arm Spacer
42 1 Right Pedal
43 4* 3/4” Axle Cap
44 1 M4 x 16mm Flat Screw
45 1 Console Bracket
46 2 Front Stabilizer Endcap
47 2 M10 x 75mm Carriage Bolt
48 1 Cable Clamp Assembly
49 1 M4 x 64mm Button Screw
50 1 Resistance Control Knob
51 4 M5 x 28mm Button Screw
52 1 Return Spring
53 2 8.5 Washer
54 4 M6 x 16mm Button Screw
55 2 M6 Nylon Locknut
56 6 Pivot Bushing
57 2* 5/8” Axle Cap
58 1 Lower Cable
59 2 Crank Arm
60 2 M10 x 68mm Carriage Bolt
61 1 Reed Switch Clamp
62 1 Extension Wire
63 2 T-handle Endcap
64 1 Plastic Washer
65 1 Crank Arm Plastic Spacer
# 1 Grease Packet
# 1 User’s Manual
# 2 Side Shield Decal
# 1 Warning Decal
# 1 Hardware Kit
