ASSEMBLY
STEP 6
Slide Shroud w/Slot (33) down into bolt (View A) at rear of weight stack
and secure to Top Guide Rod Frame (8) using:
1 x (91) Bolt 1 x (92) Washer
Secure Shroud (32) to Top Guide Rod Frame (8) and Base Frame for
Weight (9) using:
2 x (91) Bolt 2 x (92) Washer
STEP 6 CONTINUED ON PAGE 9
TIGHTEN ALL BOLTS AND NUTS BEFORE PROCEEDING.
