DO NOT CUT STRAPS UNTIL STEP 1-E!* Disassemble box and remove the
cardboard packaging that is not beneath the treadmill. Do not attempt to lift the
treadmill at this time. Remove plastic wrap from console masts.
Open HARDWARE BAG 1.
Lift LEFT CONSOLE MAST into
upright position. Be sure to hold
the console mast firmly, as it
will not stay in the upright
position on it’s own.
Move LEFT SIDE LINKAGE ARM
into position. Insert BOLT (A)
and tighten.
Repeat on the right side.
Now cut the banding straps and
remove remaining packaging
material.*
P R E - A S S E M B LY
WARNING
A S S E M B LY S T E P 1
A
B
C
D
E
BOLT (A)
45 mm
Qty: 2
HARDWARE BAG 1 CONTENTS :
BOLT (A)
LOWER
LINKAGE
ARM
BOLT (B) NUT (C)
LINK ARM COVER
TIME
DISTAN
CE
CALOR
IES
PU
LSE
INC
LINE
SPEED
1
MPH
2
MPH
3
MPH
4
MP
H
5
MPH
6
MP
H
7
M
P
H
8
MPH
9
MPH
1
0
MPH
PR
ESS
ENTER
TO S
ET
SPEE
D
MAG
NETI
C KEY
1
.
3
T
INCLINE
SPEED
INCLINE
%
SPEED
MPH
STOP
HOLD TO
RE
SE
T
START
QUICK STAR
T
ENTER
C
HA
N
GE DI
S
PLAY
1
2
3
4
5 67 8
9
1
0
1
2
3
4
5
6
7 89
1
0
A S S E M B LY S T E P 2
BOLT (A)
LOWER
LINKAGE
ARM
BOLT (B) NUT (C)
LINK ARM COVER
TIME
DISTA N
CE
CALOR
IES
PU
LSE
INC
LINE
SPEED
1
MPH
2
MPH
3
MPH
4
MP
H
5
MPH
6
MP
H
7
M
P
H
8
MPH
9
MPH
1
0
MPH
PR
ESS
ENTER
TO S
ET
SPEE
D
MAG
NETI
C KEY
1
.
3
T
INCLI NE
SPEED
INCLINE
%
SPEED
MPH
STOP
HOLD TO
RE
SE
T
STAR T
QUICK STAR
T
ENTE R
C
HA
N
GE DI
S
PLAY
1
2
3
4
5
6
78
9
1
0
1
2
3
4
5
6
78
9
1
0
#0-5#
NN
2UZ
/:-0/
/65$
NN
2UZ
HARDWARE BAG 2 CONTENTS :
Open HARDWARE BAG 2.
Lift CONSOLE (as shown) to lock
it into place.
Insert BOLT (B) through
CONSOLE MAST and secure
using NUT (C).
Repeat on other side.
Note: Do not pinch the wires.
A
B
C
D
$0/40-&."45
* NOTE: If the straps have been removed
before completing step 1-D and the
linkage arms cannot be aligned, refer
to the TROUBLESHOOTING section
(page 35) in order to restore the
treadmill to its proper position.
A S S E M B LY S T E P 3
BOLT (D)
CONSOLE MAST COVER
BOLT (D)
16 mm
Qty: 6
HARDWARE BAG 3 CONTENTS :
WATERBOTTLE
HOLDER
SAFETY KEY
Open HARDWARE BAG 3.
Place CONSOLE MAST COVERS
over CONSOLE MASTS as shown.
Attach CONSOLE MAST COVERS
using 6 BOLTS (D).
Place WATER BOTTLE HOLDERS
and SAFETY KEY into the correct
positions. It is now safe to plug
in your treadmill.
A
B
C
D
Y O U ’ R E F I N I S H E D !
