The information in this manual furnished for information use only, is subject to change without notice,
is not to be construed as a commitment by ATN Corp.
ATN Corp. assumes no responsibility or liability for any errors or inaccuracies that may appear in this book.
©2001 ATN Corp. All right reserved.
Optional focal length
doubler gives the
Viper increased
magnification, in just
seconds, without any
tools.
Builtin infra-red illuminator
1’ to Infinity focus
35mm F 1:1.4 lens
for maximum clarity
One 3 volt battery
Master power
5 Diopter
Camera
adapter
FEATURES
• Great for hunting, camping, boating or surveillance
• Total darkness technology
• Automatic brightness control
• Built-in IR illuminator
• Manual focus
• Adjustable eyepiece
• High res. 1st Gen+ intensifier tube
• Rugged and versatile design
• Light weight and comfortable
• Water and dust resistant
• Single switch button operation
• Superb 1X lens system
• Optional Doubler & Lens allows 4X to 8X magnification
• Soft case
• Two years warranty (optional extended warranty)
SPECIFICATIONS
Magnification ....................... 1X (Optional 4X, 8X)
Intensifier tube ..................... 1st Gen.+; high res.
Lens System........................ 35 mm; F1:1.4
Field of view......................... 20°
Resolution ........................... 40lp/mm
Minimum light Req. .............. 5X10
-3
lux
Range of Focus.................... 1’ to
Power Supply....................... 3 volt lithium
Battery Life .......................... 10-20 hours
Operating Temp................... -30°F to +110°F
Dimensions.......................... 137mm X 87mm X 43mm
Weight.................................. 6.5 oz
