1 Speakers 5 Brightness sensor
2 Num lock indicator 6 Power button
3 Caps lock indicator 7 Left and right buttons
4 Scroll lock indicator
Back
1 DC In port 4 AV Out jack
2 USB 2.0 ports
1
5 Monitor (VGA) port
3 Network (Ethernet) port 6 Air vent
1
Supports high-/full-/low- speeds.
Only connect 10BASE-T, 100BASE-TX, 1000BASE-TX cables to the Network (Ethernet) port. Do not
connect any other type of network cable or any telephone line to this port. Connecting cables other than those listed
above may result in an electric current overload and could cause a malfunction, excessive heat, or fire in the port.
To connect the unit to a network, refer to your on-screen VAIO
®
Computer User Guide or contact your network
administrator.
Left
