VAIO Notebook User Guide
72
❑ Projector (See “To connect a projector”.)
To connect a computer display
❑ Locate the Monitor connector identified by the symbol on the back of the
computer. Plug the display cable (not supplied) into this connector.
❑ If necessary, plug one end of the display power cord into the display, and the
other end into an AC outlet.
To connect a multimedia computer display
You can connect the notebook to a multimedia computer display that includes
built-in speakers and a microphone.
1 Locate the Monitor connector identified by the symbol. Plug the display
cable into this connector.
2 Locate the Headphone connector identified by the symbol. Plug the
speaker cable into this connector.
3 Locate the Microphone connector identified by the symbol. Plug the
microphone cable into this connector.
✍ Connect an external display before you turn on the computer.
Connecting an external computer display
✍ See the manual that came with your computer display for more information on
installation and use.
Computer display
Power cord
To
Display cable (optional)
Monitor
