Table 9: SCSI Fast-160 and fast 320 non-compensatable timing budget in nanoseconds
Item
Fast-160 Fast-320
Comments
REQ(ACK) period
12.5 6.25
From Table 7
Transfer period
6.25 3.125
REQ(ACK) period / 2
Transmitter and receiver errors:
Total
Errors
Post
Compen
sation
Total
Errors
Post
Compen
sation
Worst case total of + and - time
shift except where noted
Transmitter errors:
REQ(ACK) period tolerance / 2
0.06 0.06 0.06 0.06
Tolerance of transmitter plus mea-
surement error
b
Clock Jitter
0.25 0.25 0.25 0.50
System noise at transmitter
0.25 0.25 0.2 0.2
Time impact
Transmitter chip skew
0.75 0 0.75 0
Transmitter trace skew
0.2 0 0.2 0
Transmit time asymmetry
0.50 0.50 0.50 0
Compensated for on fast-320
SCSI devices
Total transmitter error budget:
2.01 1.06 1.96 0.51
Receiver errors:
System noise at receiver
0.25 0.25 0.2 0.2
Time impact
Chip noise in receiver
0.2 0.2 0.2 0.2
Time impact
Receiver chip skew
0.75 0 0.75 0
Receiver trace skew
0.2 0 0.2 0
Receiver time asymmetry
0.35 0.35 0.35 0
Residual skew error
0 0.3 0 0.2
After skew compensation
Strobe offset tolerance
0 0.5 0 0.2
Accuracy of centering strobe
Offset induced time asymmetry
N/A
a
N/A
a
0.8 0.2
Time impact from cumulative D.C.
offsets at receiver
Receiver amplitude time skew
0.2 0.2 0.2 0.05
Total receiver error budget:
1.95 1.8 2.7 1.05
Total Transmitter + receiver error
budget:
3.96 2.86 4.44 1.53
Total timing error budget for
interconnect and system margin:
2.29 3.39 -1.535 1.565
Transfer period - (total transmitter
+ total receiver error budget)
a Timing budgets in some previous standards neglected asymmetry & detection ambiguity and
lumps chip noise, clock jitter, crosstalk time shift, noise, ISI and receiver amplitude skew into
other terms (e.g., signal distortion skew) and/or ignores the effects.
b Tolerance adjusted for half cycle (i.e., transfer period)
