INSTALLATION This section contains the following installation topics:
• “Pre-Installation” on page 7
• “Installation Procedures” on page 8
• “Start-Up Sequence” on page 30
Pre-Installation The pre-installation checklist and site planning must be performed before
installing the equipment at the site.
Receiving The equipment required for each PowerLogic EM4800 meter installation
includes:
• high-density meter (PowerLogic EM4833, PowerLogic EM4880 or
PowerLogic EM4805)
• For the PowerLogic EM4833 and PowerLogic EM4880, one 12-ft (4-m)
AMP cable with one 50-pin connector supplied with each unit
• For the PowerLogic EM4805, two Mate-n-Lok
TM
wiring harnesses
supplied with each unit in 8-, 12-, or 24-connector variants
• CD and meter configuration software, this installation manual and an
installation record form
When you receive your order, verify that the items listed above are included
with the shipment, and visually inspect them for damage. If any parts are
missing or damaged, contact your Schneider Electric representative.
Pre-Installation Checklist The installer must provide the following information, tools, and equipment
before proceeding with the installation:
• certified current transformers for metering (not supplied)
• an appropriate 15-Amp maximum circuit breaker or a fused disconnect
switch for the type of panel
• current/voltage meter to test the phasing of panels
• RJ45 Ethernet patch cable
• 4-wire 14 AWG (1.63 mm
2
) cable for three-phase wye connected
circuits, or 3-wire 14 AWG (1.63 mm
2
) cable for a single-phase wye
connected circuits
• small flat-head screwdriver
• #2 Phillips screwdriver
• crimping tool
• 18 AWG butt splice connector
• wire strippers
• four 1-inch (25 mm) #8 mounting screws suitable for selected mounting
surface
