8-16
Exploded View & Parts List
Samsung Electronics
Service Manual
No. Description SEC.Code Q’ty SA Remark
0 MEA UNIT-CASSETTE_MB JC97-01914A 1 O
1 ADJUST-M-CASSETTE_L JC70-00300A 1 O
2 ADJUST-M-CASSETTE_R JC70-00301A 1 O
3 GEAR-PINION JG66-40003A 13 GEAR-PINION JG66-40003A 1 O
4 IPR-PLATE PAD JC70-00314A 1 O
5 RPR-FRICTION PAD JC73-00140A 1 O
6 SHEET-HOLDER PAD JC63-00290A 1 X
7 HOLDER-M-PAD JC61-00580A 1 O
8 SPRING ETC-LOCKER,PLATE JG61-70531A 1 O
9 PLATE-P-KNOCK_UP JC61-00603A 1 X
10 SPRING-CS 6107-001166 2 X
11 PMO-EXTENSION SMALL JC72-00971A 1 O
12 GUIDE-M-EXTENSION L2 JC61-00918B 1 X
13 FRAME-M_CASSETTE JC61-00876A 1 X
14 PMO-PLATE_LOCKER JC72-00972A 1 O
15 SPRING ETC-EXIT ROLL FD JC61-70911A 1 X
16 ROLLER-M-IDLE FEED JC66-00529A 2 O
17 SPRING-ES 6107-001047 2 X
18 GUIDE-M_CASSETTE JC61-00944A 1 X
19 CAM-M-KNOCK_UP JC66-00719A 1 X
20 RPR-PAD CASSETTE JC73-00141A 1 X
Cassette Unit Assembly Parts List
SA : Service Available
O : Service available X : Service not available
