Specifications
F16
Technical Notes and Index
ISO sensitivity (Standard
output sensitivity)
• ISO 80, 100, 200, 400, 800, 1600, 3200, 6400
• Auto (auto gain from ISO 80 to 800)
• Fixed range auto (ISO 80 to 200, 80 to 400)
Exposure
Metering 256-segment matrix, center-weighted (digital zoom less than
2×), spot (digital zoom 2× or more)
Exposure control Programmed auto exposure with motion detection and
exposure compensation
(–2.0 to +2.0 EV in steps of
1
/3 EV)
Shutter Mechanical and charge-coupled electronic shutter
Speed
1
/1500–1 s
4 s (when scene mode is set to Fireworks show)
Aperture Electronically-controlled ND filter (–2 AV) selection
Range 2 steps (f/3.9 and f/7.8 [W])
Self-timer Can be selected from 10 and 2 second duration
Built-in flash
Range (approx.)
(ISO sensitivity:
Auto
)
[W]: 0.3 to 4.5 m (1 ft to 14ft)
[T]: 0.5 to 3.5 m (1 ft 8 in. to 11 ft)
Flash control TTL auto flash with monitor preflashes
Interface Hi-Speed USB
Data Transfer Protocol MTP, PTP
Video output Can be selected from NTSC and PAL
I/O terminal Audio video output/digital I/O (USB), Projector input
connector (for Dock Connector Cable)
Projector
Projection system Three-lamp/single-panel color-sequential system
Display element Reflective digital micromirror device (DMD)
Projector lens 13mm f/2.1, manual focus
Light source High luminosity LED (1 each of R, G, B)
Image size 13 to 152 cm (5 to 60-in.)
Throw distance Approx. 0.26 to 3.1 m (11 in. to 10 ft)
Number of colors Full color (approx. 16.7 million colors)
Brightness
1
Up to 20 lumens
Contrast ratio 200:1
Resolution (output) VGA
Endurance (battery
life)
Approx. 1 h with EN-EL12 battery
