39
Troubleshooting
OTHERS
Symptom Remedy
The operation becomes un-
stable
The auto iris will not operate
There is noise in the screen
or increase in residual images
The colors of the screen are
not natural
White balance adjusted
automatically/manually
cannot be used
The camera title will not ap-
pear
The vertical phase cannot be
adjusted using the V PHASE
menu item
Drop in voltage of the power supply can
be considered. Check the length and thick-
ness of the power supply cable.
(੬ Page 17)
Set the VIDEO/DC switch on the side of
unit according to the type of auto iris lens
used.
(੬ Pages 20, 21)
Lower the gain using the AGC MODE
menu item.
SUPER HIGH LOW OFF
(MAX) (MIN)
Gain
(੬ Page 29)
When using in an environment where there
are changes in the light source, set the
WHITE BALANCE menu item to ATW.
(੬ Page 32)
Set the WHITE BALANCE menu item to
AWB or MANUAL.
(੬ Page 32)
Set the CAMERA TITLE menu item to ON.
(੬ Page 35)
When adjusting the vertical phase during
line lock, set the LL/INT switch on the back
of unit to LL.
(੬ Page 35)
