EN39
Controls
1 Stop Button [STOP] .............................. ੬ pg. 30
2 •Retake Rewind Button [RETAKE R]..... ੬ pg. 18
•Quick Review Button [ R] ............ ੬ pg. 18
•Rewind Button [R]............................. ੬ pg. 30
3 Play/Pause Button ................................ ੬ pg. 30
4 •Retake Forward Button [RETAKE F] .... ੬ pg. 18
•Fast-Forward Button [F] ..................... ੬ pg. 30
5 •Fade/Wipe Button [FADE/WIPE] ........ ੬ pg. 19
•Counter Reset/Memory Button
[COUNTER R/M] .............................. ੬ pg. 31
6 Program AE Button [P. AE].................... ੬ pg. 20
7 Digital Effect Button [DIGIFECT] .......... ੬ pg. 21
8 REFRESH Button .................................... ੬ pg. 6
9 EJECT Switch ....................................... ੬ pg. 13
0 Close Button........................................ ੬ pg. 13
! •MENU Wheel [–, +] .......................... ੬ pg. 22
•TRACKING Wheel [–, +]................... ੬ pg. 31
@ 5-Second Recording Button
[5 SEC. REC]........................................ ੬ pg. 18
# Power Zoom Lever [T/W]..................... ੬ pg. 16
$ •Picture Stabilizer Button
[P. STABILIZER] ................................. ੬ pg. 17
•Time Base Corrector Button [TBC] ..... ੬ pg. 31
% Power Switch
[ , OFF, , ] ...................... ੬ pg. 14, 30
^ Recording Start/Stop Button.................. ੬ pg. 14
& Battery Release Switch
[BATTERY RELEASE] .............................. ੬ pg. 6
* Diopter Adjustment Control ................... ੬ pg. 8
Connectors
The connectors ( to w are located beneath the
cover.
( S-Video Output Connector [S] .............. ੬ pg. 32
) Audio Output Connector [A]................ ੬ pg. 32
q Video Output Connector [V] ................ ੬ pg. 32
w DC IN Connector............................... ੬ pg. 6, 7
Indicators
e CHARGE Lamp...................................... ੬ pg. 6
r •Power Lamp ..................................... ੬ pg. 14
•REFRESH Lamp................................... ੬ pg. 6
Other Parts
t Shoulder Strap Eyelets............................ ੬ pg. 8
y Eyepiece
u Battery Pack Mount ............................... ੬ pg. 6
i Viewfinder ............................................. ੬ pg. 8
o Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
p Grip Strap.............................................. ੬ pg. 8
Q Microphone
W Tripod Mounting Socket ......................... ੬ pg. 8
