10
For more details, refer to the Detailed User Guide at http://manual3.jvckenwood.com/
Preparation before Use
Connecting the Camera to
Your Computer
To set up the camera, fi rst connect it to
your computer.
Required operating environment
Browser: Internet Explorer 9 or later
1 Attach the supplied LAN cable to
the camera.
DIRECTWLAN
RESET
LAN(OFF)
ETHERENT
BATT.
DC
AV
MIC
PLUG IN POWER
2 Connect the camera to your
computer via the LAN cable.
3 Set the network mode switch to
[LAN
•
OFF].
DIRECTWLAN
RESET
LAN(OFF)
ETHERENT
DC
AV
MIC
PLUG IN POWER
DIRECT WLAN LAN(OFF)
• If the network mode switch is set to
[DIRECT] or [WLAN], the LAN terminal
cannot be used.
• While the power is on, switching the
network mode switch does not change
the setting.
• Do not use cables (AV cable,
microphone, etc.) with L-shaped
connecters.
• For other ways of connecting, see
"Detailed User Guide".
Connecting the AC Adapter
Connect the supplied AC adapter to the
DC connector.
DIRECTWLAN
RESET
LAN(OFF)
ETHERENT
DC
AV
MIC
PLUG IN POWER
