EN57
Controls
1 Dioptre Adjustment Control ................. ੬ pg. 12
2 Lens Cover Open/Close Ring
[LENS COVER] .................................... ੬ pg. 14
3 Video Light Switch
[LIGHT OFF/AUTO/ON]
(GR-FXM45 only)................................. ੬ pg. 21
4 •Snapshot Button [SNAPSHOT]
(GR-FXM45 only) .............................. ੬ pg. 20
•5-Second Recording Button
[5 SEC REC] (GR-FXM15 only)...........
੬ pg. 20
5 •Power Zoom Lever [T/W] .................. ੬ pg. 18
•Speaker Volume Control [VOL.] ........ ੬ pg. 39
6 Picture Stabilizer Button
[P.STABILIZER] ..................................... ੬ pg. 20
7 Program AE Button [P.AE]..................... ੬ pg. 24
8 Fade/Wipe Button [EFFECT] ................. ੬ pg. 23
9 •Rewind Button [
2
, REW] ................ ੬ pg. 38
•Retake Rewind Button [RETAKE R].....
੬ pg. 19
•Quick Review Button [
R] ............. ੬ pg. 19
0 •Fast-Forward Button [
3
, FF] ............ ੬ pg. 38
•Retake Forward Button [RETAKE F] .... ੬ pg. 19
! Stop Button [5, STOP]......................... ੬ pg. 38
@ Play/Pause Button
[
4
/6, PLAY/PAUSE]............................. ੬ pg. 38
# •Select Dial [+, –, PUSH]................ ੬ pg. 9, 28
•Bright Dial [BRIGHT] ........................ ੬ pg. 17
$ MENU/DISPLAY Button ................. ੬ pg. 15, 28
% •Counter Reset/Memory Button
[COUNTER R/M] .............................. ੬ pg. 40
•Recording Mode Button [SP/LP].........
੬ pg. 10
% Counter Reset/Memory Button
[COUNTER R/M] ................................. ੬ pg. 40
^ EJECT Switch ....................................... ੬ pg. 11
& Recording Start/Stop Button.................. ੬ pg. 14
* Power Switch ................................ ੬ pg. 14, 38
( Battery Release Switch
[BATTERY RELEASE] .............................. ੬ pg. 6
) PUSH Button ....................................... ੬ pg. 11
Connectors
q DC IN Jack ............................................ ੬ pg. 7
The connectors w to r are located beneath the
cover.
w Video Output Connector...................... ੬ pg. 42
e Audio Output Connector ..................... ੬ pg. 42
r J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
•Connect the editing cable when performing
Random Assemble Editing (
੬ pg. 46 – 49).
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
t Tally Lamp........................................... ੬ pg. 14
y Power Lamp ........................................ ੬ pg. 14
Other Parts
u Battery Pack Mount ............................... ੬ pg. 6
i Viewfinder ........................................... ੬ pg. 12
o Grip Strap............................................ ੬ pg. 12
p •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor .................................. ੬ pg. 45
Q Video Light (GR-FXM45 only) .............. ੬ pg. 21
W Microphone......................................... ੬ pg. 51
E Eyepiece.............................................. ੬ pg. 52
R Speaker ............................................... ੬ pg. 39
T LCD Monitor ....................................... ੬ pg. 17
Y Shoulder Strap Eyelets .......................... ੬ pg. 13
U Clock Battery Slot .................................. ੬ pg. 8
I Tripod Mounting Socket ....................... ੬ pg. 13
