*This output level of a standard signal generator (SSG) is indicated as SSG’s open circuit.
RECEIVER ADJUSTMENTS (continued)
430 M PEAK
(MAIN BAND)
430 M PEAK
(SUB BAND)
430 M
TOTAL GAIN
(MAIN BAND)
NOISE
BLANKER
(MAIN BAND)
(SUB BAND)
1
1
1
2
1
2
3
4
• Display frequency: 435.0200 MHz
• Mode : FM
• Connect a standard signal generator
to [UHF ANT] connector and set as:
Frequency : 435.0200 MHz
Level : 1 µV* (–107 dBm)
Modulation:
1 kHz/±5.0 kHz Dev.
• Receiving
• Sub display freq. : 435.0200 MHz
• Mode : FM
• Set an SSG as :
Frequency : 435.0200 MHz
Level : 1 µV* (–107 dBm)
Modulation:
1 kHz/±5.0 kHz Dev.
• Receiving
• Display frequency: 435.0200 MHz
• Mode : USB
• Set an SSG as :
Frequency : 435.0215 MHz
Level : 1 mV* (–47 dBm)
Modulation:
OFF
• Receiving
• Set an SSG as :
Level : OFF
• Receiving
• Display frequency: 145.9800 MHz
• Mode : USB
• [NB] : OFF
• Connect an SSG to [VHF ANT] con-
nector and set as :
Frequency : 145.98150 MHz
Level : 5.6 µV* (–92 dBm)
Modulation: OFF
and apply following signal to [VHF
ANT] connector.
• Receiving
• [NB] : ON
• Set an SSG as :
Level : 3.2 µV* (–97 dBm)
•
Receiving
• Sub display freq. : 145.9800 MHz
• Mode : USB
• [NB] : OFF
• Set an SSG as :
Level : 5.6 µV* (–92 dBm)
•
Receiving
• [NB] : ON
• Set an SSG as :
Level : 3.2 µV* (–97 dBm)
•
Receiving
MAIN
MAIN
Rear
panel
MAIN
