41
Figure 6. Configuration Menu Overview
OFFLINE
CONFIG.
CONTROL
page 71
ACTIVE
EMULATION
1
page 73
EMULATION
page 74
MAINT/MISC
page 109
HOST
INTERFACE
page 110
Load Config.
Save Config.
Print Config.
Delete Config.
Power-Up Config.
Protect Configs.
PCL-II*
LP PLUS
IGP/PGL & LP+
IGP/VGL & LP+
PCL-II*
LP PLUS
2
IGP/PGL & LP+
3
IGP/VGL & LP+
3
Hex Dump Mode
Power-up State
Display Language
Power Stacker
3
Bi-Tronics*
Centronics
Serial
Ethernet
3
Auto Switching
ETHERNET
PARAMS
3
page 120
PRINTER
CONTROL
page 121
IP Address
Gateway Address
Subnet Mask
MAC Address
Novell Protocol
NetBIOS Protocol
Novell Frame
PPM Port Number
PPM Port Timeout
Ethernet Speed
Unidirectional
PMD Fault
Slow Paper Slew
Power Saver Time
1
Choices available are limited to the emulations
installed on the printer.
2
Appears only if LP Plus is the active emulation.
3
Appears only if installed.
DIAGNOSTICS
page 123
RIBBON
MINDER
page 126
Printer Tests
Test Width
Paper Out Dots
System Memory
Print Statistics
New Ribbon
Ribbon Action
Ribbon Size
Ribbon Adjust
Fault Action
To view options, press: 6 Down
5 Up
4 Next
3 Prev
To select an option, press ENTER.
To return to main menu, press
CLEAR.
To exit menu, press ON LINE.
* = Default Setting
