Information Menu 37
The following table describes the IEEE 802.1x parameters.
Table 21 802.1x information
Field Description
Port
Displays each port’s name.
Auth Mode
Displays the Access Control authorization mode for the port.
The Authorization
mode can be one of the following:
• force-unauth
• auto
• force-auth
Auth Status
Displays the current authorization status of the port, either
authorized or unauthorized.
Authenticator PAE State
Displays the Authenticator Port Access Entity State. The PAE
state can be one of the following:
• initialize
• disconnected
• connecting
• authenticating
• authenticated
• aborting
• held
• forceAuth
Backend Auth State
Displays the Backend Authorization State. The Backend
Authorization state can be one of the following:
• request
• response
• success
• fail
• timeout
• idle
Spanning Tree information
Command: /info/l2/stp
------------------------------------------------------------------
upfast disabled, update 40
------------------------------------------------------------------
Spanning Tree Group 1: On (STP/PVST+)
VLANs: 1
Current Root: Path-Cost Port Hello MaxAge FwdDel
8000 00:02:a5:d1:0f:ed 8 20 2 20 15
Parameters: Priority Hello MaxAge FwdDel Aging
32768 2 20 15 180
Port Priority Cost FastFwd State Designated Bridge Des Port
---- -------- ---- -------- ---------- --------------------- -------
1 0 0 n FORWARDING *
2 0 0 n FORWARDING *
3 0 0 n FORWARDING *
