Physical and Operating Specifications
This chapter provides physical and operating specifications for the HP ProLiant DL185 G5 server.
Specifications include:
System Unit
Table 11 Hardware Specifications
Item Components
Processor socket AMD F1207
Processor support 2P AMD Opteron 2000 series processor
Chipset HT2100 /HT1000
Hardware monitoring device ServerEngines management controller
Gigabit Ethernet controller
BCM5704C dual GbE channels support
IDE controllers HT1000
Embedded video controller ServerEngines VGA core integrated into Pilot
I/O subsystem
• Two PCIe x8 links with x8 slot
• One PCIe x4 links with x8 slot
Memory Eight DDR2-667 MHz DIMM slots with ECC, up to 32
GB
Default media storage One-half height IDE CD-ROM drive, SATA hard drive
Optional media storage
• One slim ODD drive bay for CD-ROM/DVD-ROM
drive, non-hot-plug SATA hard drive, and SAS
device
• Eight bays hot-plug HDD cage for SAS or SATA
drives
I/O ports PS2 keyboard port, PS2 mouse port, USB 2.0 ports
(two rear USB ports, one internal USB port (J 21), two
front USB ports), video port, serial port and GbE port.
Status LED indicators
Front panel
Rear Panel
System Board
• NIC 1/2 activity
• Power LED
• Health LED
• UID LED
• UID SW/LED
• LAN link status
• Management processor indicator
