DesignJet 750CPlus (D-size)
HP Parts Reference Guide™
External Case Parts
Cross-Brace
69
C3192-60001 Cross-brace - Main structure that extends between stand legs
Foot
70
C4696-60006 Foot assembly (includes casters)
Hardware
71
0624-0771 Plastite screw (threaded insert mold-in, Textron K40) - M4.0 x 0.7, 20mm long, Torx T15
Hardware Kit
72
C4704-60095 Hardware kit for printer stand - Includes screwdriver, screws, washers, and media bin retaining clips
Housing
73
C4705-60092 Electronic housing assembly (PC board enclosure)
Keycap
74
5041-1203 Power switch keycap (White)
Latch
75
C3195-40060 Center cover latch - Two 'T' shaped latches are used to connect ends of center cover to left and right end covers
Leg
76
C4696-60007 Leg assembly - Side support for the plotter - Does NOT include the foot assembly
Nameplate/Logo
77
C4708-00020 Nameplate - DesignJet 750C Plus
Overlay
78
C3195-60041 Front panel overlay (Self adhesive) - Shows the function of the front panel buttons and indicator lights (English)
79
C3195-60042 Front panel overlay (Self adhesive) - Shows the function of the front panel buttons and indicator lights (Korean)
80
C3195-60043 Front panel overlay (Self adhesive) - Shows the function of the front panel buttons and indicator lights (Taiwan)
81
C3195-60044 Front panel overlay (Self adhesive) - Shows the function of the front panel buttons and indicator lights (German)
82
C3195-60045 Front panel overlay (Self adhesive) - Shows the function of the front panel buttons and indicator lights (French)
83
C3195-60046 Front panel overlay (Self adhesive) - Shows the function of the front panel buttons and indicator lights (Spanish)
84
C3195-60047 Front panel overlay (Self adhesive) - Shows the function of the front panel buttons and indicator lights (Italian)
85
C3195-60048 Front panel overlay (Self adhesive) - Shows the function of the front panel buttons and indicator lights (Japanese)
86
C3195-60049 Front panel overlay (Self adhesive) - Shows the function of the front panel buttons and indicator lights (Portuguese)
87
C3195-60050 Front panel overlay (Self adhesive) - Shows the function of the front panel buttons and indicator lights (Chinese)
Window
88
C4705-60087 Lift-up viewing window
Optional Interfaces
Interface (Module)
89
J4101-61011 External JetDirect 300X print server module (10Base-T and 100Base-T) - Connects between printer parallel port and
LAN network - Does NOT include power module - (J4101A, J4101B)
Interface (Product)
90
J2550B EtherTwist (10Base-T) LAN interface board
NO LONGER SUPPLIED
91
J2552B LAN & LocalTalk interface - Has EtherTwist (10Base-T) , ThinLAN (10Base-2) , and LocalTalk (DIN-8) connectors
NO LONGER SUPPLIED
92
J2555B Token ring LAN interface board - DB-9 and RJ-45 connectors
NO LONGER SUPPLIED
93
J2590A External JetDirect LAN interface module with RJ-45 connector for EtherTwist (10Base-T) or 100VG/802.12 input and 3
parallel (DB-25) output connectors
NO LONGER SUPPLIED
94
J2591A External JetDirect LAN interface module and power module - Has EtherTwist (10Base-T) and ThinLAN (10Base-2)
connectors
NO LONGER SUPPLIED
