13-80
Configuring for Network Management Applications
LLDP (Link-Layer Discovery Protocol)
Note For details on how to use an SNMP utility to retrieve information from the
switch’s CDP Neighbors table maintained in the switch’s MIB (Management
Information Base), refer to the documentation provided with the particular
SNMP utility.
Viewing the Switch’s Current CDP Configuration. CDP is shown as
enabled/disabled both globally on the switch and on a per-port basis.
The following example shows the default CDP configuration.
Figure 13-25. Example of Show CDP with the Default CDP Configuration
Command Page
show cdp 13-80
show cdp neighbors [< port-list > detail]
[detail < port-list >]
13-81
[no] cdp run 13-81
[no] cdp enable < port-list > 13-82
Syntax: show cdp
Lists the switch’s global and per-port CDP configuration.
ProCurve# show cdp
Global CDP information
Enable CDP [Yes] : Yes (Receive Only)
Port CDP
---- --------
D1 enabled
D2 enabled
D3 enabled
D4 enabled
. .
. .
. .
