Setup
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure Description
Qty.
Use
Front wheels 2
Shim washers (as required)
2
Flat washers 2
Cotter pins
2
1
Hub caps 2
Install the front wheels.
2
No parts required
–
Check the tyre pressure.
Steering wheel
1
3
Spirol pin
1
Install the steering wheel.
Seat
1
Knobs 2
4
Flat-washer 2
Install the seat.
Bulk electrolyte, 1.260 specic gravity
(purchase separately)
As
needed
Bolt (1/4 x 3/4 inch)
2
5
Wing nut 2
Activate the battery.
6
No parts required
–
Check the engine oil level.
Anti-scalp wheels 2
Wheel bolt 2
7
Locknut 2
Install the anti-scalp wheels.
8
No parts required
–
Preparing the cutter deck discharge
chute.
9
No parts required
–
Lubricate the tractor.
10
No parts required
–
Check the safety interlock system.
11
No parts required
–
Purge the hydro transaxle,
12
No parts required
–
Check the hydro neutral position.
13
No parts required
–
Check the traction control pedal.
Media and Additional Parts
Description
Qty.
Use
Ignition key 1
Start the engine.
Reverse interlock key 1 Enable mowing operation in reverse.
Lift assist spring removal tool
1
Save for future maintenance use.
Operator’s Manual
1
Read before operating.
Certicate of Conformance
1
Noise certicate
1
CE conformance
