For a Pool/Spa Setup selection of “Pool Only”, “Spa Only” or “Pool and Spa-Std”, Heater1
and/or Heater2 cooldown affect the filter pump. For “Pool and Spa-Dual”, Heater1 is associated
with the spa filter and Heater2 with the pool filter.
Heater Extend
If “Enabled”, the filter extend logic keeps the filter pump running beyond the normal turn-off
time until the pool (or spa) is heated up to the desired temperature setting (see Settings
Menu). Heater extend will NOT cause the filter pump to turn on, it will only delay the turn
off time when the heater is operating.
For a Pool/Spa Setup selection of “Pool Only”, “Spa Only” or “Pool and Spa-Std”, Heater1
and/or Heater2 will keep the filter pump running. For “Pool and Spa-Dual”, Heater1 will keep
the spa filter running and Heater2 will keep the pool filter running.
Allow Low Speed
This menu only appears if the pool filter is configured for 2-speed operation. During default
operation, high speed mode is used whenever the heater is on. If Allow Low Speed is
enabled, low speed will be allowed even if the heater is on.
Solar Config.
+ to view/change
Solar
Disabled
Solar-Extend
Disabled
Solar Priority
Disabled
Push to access solar options
Toggle between Enabled and Disabled (default) Solar
Toggle between Enabled and Disabled (default) Solar Extend
Toggle between Enabled and Disabled (default) Solar Priority
Move to previous/next configuration menu
Move to next menu item or previous/next configuration menu
Move to next menu item
Move to previous/next configuration menu
if “Solar” is enabled
if “Solar” is enabled
+
+
>
>
>
>
Solar
The Solar configuration menu will NOT appear if “Pool and Spa - Dual” has been selected in
the Pool/Spa setup menu. If the solar control logic is “Enabled”, several additional steps
must be taken to ensure proper operation of the solar heating system. If the solar is operated
by a valve, then a valve (Valve3 or Valve4) output must be setup for solar logic (page 29). If
the solar is operated by a pump, then one of the AUX relays must be set up for solar logic
(page 31). Also, the “solar” temperature sensor must be installed. This sensor is typically
mounted near the collector array and is used to sense whether sufficient solar heat is available.
If solar is “Enabled”, the valve or solar pump relay will turn on when the water temperature is
less than the desired temperature setting AND the solar sensor is hotter than the water by at
least 8ºF. The desired temperature is in the “Settings Menu”. If applicable, the homeowner
will be prompted to enter separate pool and spa desired temperature settings. Depending on
the position of the pool/spa suction valve, the proper temperature setting will be used.
Solar Extend
If “Enabled”, the filter extend logic keeps the filter pump running beyond the normal turn-off
time if solar heat is still available. When solar heat is no longer available, both the solar
valve/pump and filter pump will turn off simultaneously. Solar extend will NOT cause the
filter pump to turn on, it will only delay the turn off time when solar is operating.
Solar Priority
If both “Solar Control” and “Heater Control” are enabled, the Solar Priority feature will keep
the conventional heater off whenever solar heat is available. This provides the most cost
effective way of heating the pool. When solar heat is not available, the conventional heater
will operate normally.
Lights Config.
+ to view/change
Lights Function
Manual On/Off
Lights Name
Pool Light
Lights Relay
Standard
Push to access Lights options
Rotates between
Manual On/Off (default), Countdown Timer, Low Speed-
Filter, Timeclock, Solar, Low speed-Spa Filter, Group, and Super Chlorinate
Rotates between all available names
Toggle between Standard (default) and Dimmer
Move to previous/next configuration menu
Move to next menu item
Move to next menu item
Move to next menu item or previous/next configuration menu
Lights Interlock
Disable
Lights Freeze
Disable
Toggle between Enabled and Disabled (default) Lights Interlock
Toggle between Enabled and Disabled (default) Lights Freeze
Move to next menu item
Move to previous/next configuration menu
+
+
+
+
+
+
>
>
>
>
>
>
>
>
>
>
>
>
for all functions except solar, dimmer relay,
low speed (filter pump), and group
for all functions except dimmer relay,
low speed, and group
for manual on/off, countdown
timer and timeclock functions
Lights Group
Filter: Unaffected
Lights Group
Timer: None(Manual)
Options available depend on the function that is selected
Rotates between Manual On/Off (default),Countdown Timer and Timeclock
Move to previous/next menu item or next configuration menu
Move to next menu item
+
+
>
>
>
>
for group function only
for group function only
Lights Name
The Aqua Logic allows you to assign any one of a number of names (e.g. “Pool Light, Spa
Light, Deck Light, etc.) to this control function. Note that other lights may be assigned to
other Aux outputs. This will make the Aqua Logic much more user friendly to the homeowner
when they want to turn various lights on or off. A sheet of small name labels is included with
the Aqua Logic main unit and each remote display/keypad so that the “Lights” pushbutton
can be labeled the same as the name that you have assigned. At this time it is also a good
idea to make sure that the relay in the control box is also labeled (hand written) with the same
name as a help to technicians who may service this system at a later date.
Lights Function
Although designated as the “Lights” output, the function of the lights relay is similar to the
Aux relays. If pool lights are wired to the lights relay, some options including Solar function,
Low Speed of a 2-Speed Filter Pump, Lights Interlock and Lights Freeze Protection are not
applicable and should be disabled. If no pool lights are used, the lights relay can be used to
control other pool devices that may require these options. The function of each option is
shown below.
Manual On/Off—the lights relay will alternate between turning on and off when the LIGHTS
button is pressed. There is no automatic control logic.
Countdown Timer—the lights relay will turn on when the LIGHTS button is pressed. The
lights relay will turn off automatically after a programmed time (see Timers Menu in Operation
Manual). The LIGHTS button can also be used to turn the output off.
Low Speed of a 2-speed Filter Pump – the Aqua Logic will turn on the lights relay whenever
the low speed operation of the filter pump is required. It is very important that the “2-speed”
filter pump option be selected under the “Filter Config.” Menu for proper operation.
Timeclock – the lights relay will turn-on and turn-off at the times set for the lights timeclock
in the Settings Menu (see Settings Menu in Operation Manual). The LIGHTS button can
also be used to turn the output on and off.
