DVS 510 Series • HTML Configuration and Control 105
Selecting a PIP input
The PIP input must be a different resolution type (high or low) from the main input. For
example, if input 1 (composite video) is your main input, the PIP input can be selected from
inputs 5 through 10 (high-resolution only). The following table shows the resolution type for
each input:
Input High Resolution Low Resolution
1 Composite
2 Composite
3 S-video
4 S-video
5 RGB, YUVp/HDTV YUVi, RGBcvS
6 RGB, YUVp/HDTV YUVi, RGBcvS
7 RGB, YUVp/HDTV YUVi, RGBcvS
8 DVI (all formats)
9 RGB, YUVp/HDTV YUVi, RGBcvS
10 DVI (all formats)
By default, the PIP image is one-fourth the size of the main window and is positioned in
the lower-right corner of the display. You can change this size using the controls on the PIP
Setup page.
To select the PIP input:
1. If necessary, select the desired main input.
2. In the PIP Selection section, click the desired input button. If your selection is valid, PIP
mode is enabled and the PIP On/Off button on the front panel lights.
NOTE: Based on the currently selected main input, the buttons for inputs with the
wrong type of resolution are grayed-out and unavailable.)
The PIP input button on the screen is highlighted and its equivalent input button on the
front panel lights green.
NOTES: • Audio or video breakaway is not available when the DVS is in PIP mode.
• Audio comes from either the main or the PIP input, depending on the
current Audio Follow setting. (The default is to follow the main
window.)
Other PIP control buttons include:
• Swap: Switches the active main window input with the PIP input. The button for the
new PIP input is highlighted on the screen.
• Off: Exits PIP mode. The highlighting is removed from the PIP input button on the
screen and the Off button is highlighted. The PIP On/Off button on the front panel
becomes unlit.
• Auto-Image: Performs an Auto-Image (adjusts the image to fill the screen) on the
selected PIP input (see “Auto Image submenu” on page 30 for more information
about the Auto-Image function).
