Construction of the Printer
Controller
Printer Machanism
Control Panel
Transformer &
Filter Circuit Board
Transformer & Filter Circuit Board
Controller
Printer Mechanism
MX-85 Dot Matrix Printer
SMDP Board (Driver Circuit Board)
Connector (male and female)
SMCT Board (Control Circuit Board)
Spacer
Controller
Fig. 8 Construction of the Printer
-8-
