60
The following optional accessories and consumables are available for purchase if required. This list of optional
accessories is current as of August, 2005. Details of accessories are subject to change without notice.
Consumables
Optional accessories
Refer to the following table and place the unit in a position which allows the best possible projection for the size of the
screen.
Units: cm (in.) Units: cm (fit.)
Units: cm (in.) Units: cm (fit.)
Optional Accessories and
Consumables
Lamp unit ELPLP33
(Lamp x1)
Use as a replacement for used lamps.
Air filter set ELPAF09
(Air filter x1)
Use as a replacement for used air filters.
50" Portable screen ELPSC06
60" Portable screen ELPSC07
80" Portable screen ELPSC08
A compact screen which can be carried easily.
(Aspect ratio 4:3)
Powered subwoofer ELPSP01
Enjoy richer, more powerful bass.
Projection Distance and Screen Size
16:9 Screen Size
Projection Distance
Minimum Maximum
(Zoom Adjustment Wide) - (Zoom Adjustment Tele)
30" 66 x 37 (26 x 15) 73 - 111 (2.4 - 3.7)
40" 89 x 50 (35 x 20) 99 - 149 (3.2 - 4.9)
60" 130 x 70 (51 x 28) 149 - 225 (4.9 - 7.4)
80" 180 x 100 (71 x 39) 200 - 301 (6.6 - 9.9)
100" 220 x 120 (87 x 47) 251 - 377 (8.2 - 12.4)
120" 270 x 150 (106 x 59) 301 - 453 (9.9 - 14.9)
150" 330 x 190 (130 x 75) 377 - 567 (12.4 - 18.6)
4:3 Screen Size
Projection Distance
Minimum Maximum
(Zoom Adjustment Wide) - (Zoom Adjustment Tele)
30" 61 x 46 (24 x 18) 90 - 136 (2.9 - 4.5)
40" 81 x 61 (32 x 24) 121 - 183 (4.0 - 6.0)
60" 120 x 90 (47 x 35) 183 - 276 (6.0 - 9.0)
80" 160 x 120 (63 x 47) 245 - 369 (8.0 - 12.1)
100" 200 x 150 (79 x 59) 307 - 462 (10.1 - 15.2)
120" 240 x 180 (94 x 71) 369 - 555 (12.1 - 18.2)
150" 300 x 230 (118 x 91) 462 - 694 (15.1 - 22.8)
