q
Power ON/STANDBY switch .......................................(21, 39, 61)
w
Power indicator ..................................................................(21, 39)
e
Power switch .....................................................................(21, 39)
r
Headphones jack (PHONES) ....................................................(43)
t
ANALOG button.................................................................(40, 42)
y
SPEAKER A/B buttons .......................................................(39, 64)
u
SURROUND BACK button .......................................................(54)
i
Preset station select buttons ...................................................(63)
o
STANDARD button.................................................(48, 50, 52, 54)
!0
5CH/7CH STEREO button........................................................(58)
!1
DIRECT/STEREO button...........................................................(42)
!2
V. AUX INPUT terminals.......................................................(5, 12)
!3
SETUP MIC jack.......................................................................(22)
!4
SURROUND MODE button......................................................(41)
!5
SURROUND PARAMETER button .....................................(50, 58)
!6
SELECT knob ...............................................................(41, 51, 59)
!7
TONE DEFEAT button ..............................................................(43)
!8
TONE CONTROL button ..........................................................(43)
!9
MASTER VOLUME control ......................................................(41)
@0
TUNING • (up) / ª (down) buttons ..........................................(62)
@1
STATUS button.........................................................................(44)
@2
DIMMER button.......................................................................(44)
@3
VIDEO SELECT button.............................................................(43)
@4
OUTPUT indicator ..............................................................(47, 54)
@5
MASTER VOLUME indicator....................................................(41)
@6
Display
@7
INPUT mode indicator..............................................................(41)
@8
SIGNAL indicator......................................................................(41)
@9
BAND button............................................................................(62)
#0
EXT. IN button....................................................................(40, 42)
#1
Remote control sensor.............................................................(18)
#2
INPUT MODE button .........................................................(40, 42)
#3
ZONE2/REC SELECT button ..............................................(44, 47)
#4
FUNCTION knob ..........................................................(40, 44, 47)
#5
MAIN button.............................................................................(40)
16
ENGLISH
