Storage
Storage eMMC 4.5.1 32/64 GB (HS200)
Battery
Type Rechargeable Li-ion Battery (32Whr)
Dimensions
Depth 224.2 mm (8.83 inches)
Height 4.45 mm (0.18 inches)
Width 78.5 mm (3.09 inches)
Weight 170.00 g (0.38 lbs)
Voltage 3.7 VDC (nominal) and 4.35 VDC (maximum)
Temperature range
Operating
Charge:
0 °C to 50 °C; 32 °F to 122 °F
Discharge:
0 °C to 70 °C; 32 °F to 158 °F
Non-Operating -20 °C to 60 °C; 4 °F to 140 °F
Coin-cell battery 3 V CR1220 lithium ion
Voltage: 3V
Capacity: 35mAh (23+/- 3 degree)
Weight: 0.8g
Temperature: -20 ~ +60 degree.
AC Adapter
Type
Input voltage 100 VAC to 240 VAC
Input current (maximum) 0.3 A
Input frequency 50 Hz to 60 Hz
Output power 10 W
Output current 5 Vdc / 2 A
Rated output voltage 5 Vdc
Temperature range:
Operating 0 °C to 40 °C (32 °F to 104 °F)
