Q-Wash 250 User Manual 4 2006-05-17/13:18
INTRODUCTION
Technical Features
Q-Wash 250
10 channel DMX Intelligent Moving Yoke Color Wash
Pan: 530°
Tilt: 280°
Pan/Tilt speed
Lamp on/off, reset
Color Wheel
- 8 dichroic colors plus white
- Rainbow color spin in both directions
Mechanical Shutter/Strobe
Mechanical Dimmer
Adjustable beam angle 8° ~ 22°
Features
- Automatic Pan/Tilt correction
- Built in automatic programs (stand-alone)
- Pan/Tilt invert option
- 16 bit Pan/Tilt resolution
- DMX Signal Indicator LED
- Display Auto Off
- Micro-stepping motors
- Thermal switch
- Fan cooled
DMX Channel Summary
CHANNEL FUNCTION
1
Pan
2
Tilt
3
Pan (Fine) 16 bit
4
Tilt (Fine) 16 bit
5
Pan/Tilt Speed
6
Lamp on/off & reset
7
Colors
8
No Function
9
Shutter/Strobe
10
Dimmer
