26
TIMER CHECKING TYPE:
Enter Start Feature ‘D’ Programming Mode:
1. Turn the Ignition ‘switch ‘ON/OFF’ 3 TIMES and stay in OFF position.
2. Push the Valet switch 9 times (holding in on the 9th push) until four
chirps with a long chirp is heard then release the valet switch. You are
now in the Start feature ‘D’ programming mode.
Select “Checking Type”:
3. Press the + transmitter button to set the “Timer Checking Type”.
[3] LED flash, [3] horn chirp to confirm this setting
4. Once you complete step 3, you can adjust and test “Start Timer” as
below:
TIMER START PROGRAMMING: (TEST & ADJUST)
While the system stay in Start Feature “D” programming mode,
1. Press the button on the transmitter to start the vehicle.
2. If everything goes well:
a. Press the button on the transmitter to stop the engine from running.
You have completed this programming successfully.
b. Press button on the transmitter to exit the program mode. There will
be 3 long chirps & 3 parking light flashes for confirmation.
3. If the crank time is too long, (Engine is running, while starter
still cranks):
a. Press the button on the transmitter to stop engine running.
b. Press the button on the transmitter to set proper “Start Timer”. The
chirp & LED pause will confirm entry. (Decrease “Start Timer” is
necessary.)
c. Repeat the step1 – 4 if necessary.
4. If the crank time is too short, (Engine not running, while starter
stops cranking):
a. Press the button on the transmitter to stop the engine from running.
b. Press button on the transmitter to set proper “Start Timer”. The
chirp & LED pause will confirm this entry. (Increase “Start Timer ” is
necessary.)
c. Repeat the step1 – 4 if necessary.
RETURN TO FACTORY DEFAULT SETTING:
1. Turn the ignition ON then OFF 3 TIMES and stay in OFF position.
2. Push the Valet switch 12 times (holding in on the 12th push) until SIX
chirps with a long chirp is heard then release the valet switch. You are
now in the “Return To Factory Default Setting” programming mode.
