100D Module Problems
The screen below displays the errors that have accumulated during the
current hour.
Console Display/Instructions
Additional Information
PC
Current hr Slot
XX
:
mm/dd/yy
hh00-hh:mm
CurAlm aaaa
MaxAlm aaaa
MIS SLP ES
BS SEC FS
xxx xxx xxx xxx xxx xxx
Exit
xx = slot number entered in Step 2
The screen below displays the errors that have accumulated during the
previous hour.
Previous hr Slot xx:
mm/dd/yy
hh:0O-hh:mm
CurAlm aaaa MaxAlm aaaa
MIIS SLP ES BS SEC FS
xxx xxx xxx xxx xxx xxx
Exit
100D Module Clock Status
xx = slot number entered in Step 2
If you have not been trained to perform T1 maintenance, contact your
technical support organization for instructions on using this procedure.
Summary
Console Procedure
Menu
Maintenance
Slot
Dial slot no.
Enter
Clock
Exit
PC Procedure
(F6)
(F2)
Type slot no.
(F10)
(F9)
(F5)
Control Unit Problems 4-83
