Reference
Designator
Part
Number
Qty Part Description
ADDITIONAL COMPONENTS
3050-0082 2 WASHER-FL NM NO. 4 .116-IN-ID .188-IN-OD
C1 0180-3899 1 CAPACITOR-FXD 220uF +-20% 50 V AL-ELCTLT
C2 0160-3334 2 CAPACITOR-FXD 0.01uF +-10% 50 V CER X7R
C9 0160-4801 1 CAPACITOR-FXD 100pF +-5% 100 V CER C0G
C11 0160-3334 CAPACITOR-FXD 0.01uF +-10% 50 V CER X7R
C17 0160-4835 10 CAPACITOR-FXD 0.1uF +-10% 50 V CER X7R
C38-C42 0160-4835 CAPACITOR-FXD 0.1uF +-10% 50 V CER X7R
C44 0180-1746 1 CAPACITOR-FXD 15uF +-10% 20 V TA
C45-C48 0160-4835 CAPACITOR-FXD 0.1uF +-10% 50 V CER X7R
CR1 1902-0557 1 DIODE-ZENER 24V 5% PD=1W IR=5UA
CR2 1901-1098 1 DIODE-SWITCHING 1N4150 50V 200MA 4NS
JM15-JM16 7175-0057 2 RESISTOR 0 MFS
LBL1 7121-7148 1 LABEL-INFORMATION .25-IN-WD .9-IN-LG
LBL2 9320-5333 1 LBL-LNE-PTR; .625-IN-WD X .25-IN-LG
PNL1 E1364-00202 1 PNL-RR RLY MUXR
R1 0757-0465 1 RESISTOR 100K +-1% .125W TF TC=0+-100
R2 0757-0453 1 RESISTOR 30.1K +-1% .125W TF TC=0+-100
R9 0757-0417 1 RESISTOR 562 +-1% .125W TF TC=0+-100
R10 0698-3451 1 RESISTOR 133K +-1% .125W TF TC=0+-100
RP1-RP4 1810-0265 4 NETWORK-RES 16-DIP 680.0 OHM X 8
RP25-RP26 1810-0279 3 NETWORK-RES 10-SIP 4.7K OHM X 9
RP32 1810-0279 NETWORK-RES 10-SIP 4.7K OHM X 9
RVT1-RVT2 0361-1231 2 RIVET-SEMITUB OVH .099DIA .36LG
RVT3-RVT4 0361-1294 2 RIVET-SEMITUB OVH .099DIA .328LG
RVT5-RVT6 0361-1295 2 RIVET-SEMITUB OVH .095DIA .406LG
U1-U4 1858-0069 4 TRANSISTOR ARRAY 18-PIN PLASTIC DIP
U5 1820-4057 1 IC BUFFER TTL/F NAND QUAD 2-INP
U6 1820-6731 1 IC GATE-ARRAY CMOS
U7-U8 1820-3079 2 IC DCDR CMOS/74HC BIN 3-TO-8-LINE
U9 1820-3081 1 IC FF CMOS/74HC D-TYPE POS-EDGE-TRIG
U10-U11 1820-3975 2 IC DRIVER CMOS/74HC LINE OCTL
U12 1820-4590 1 IC MV CMOS/74HC MONOSTBL RETRIG DUAL
U15 1820-4147 1 IC LCH CMOS/74HCT TRANSPARENT OCTL
U16 1820-3714 2 IC TRANSCEIVER TTL/ALS BUS OCTL
U17-U18 1820-3631 2 IC COMPARATOR CMOS/74HCT MAGTD 8-BIT
U19 1820-3664 1 IC GATE CMOS/HCT NAND QUAD 2-INP
U20 1820-4242 1 IC SCHMITT-TRIG CMOS/74HCT INV HEX
U21-U22 1820-4643 2 IC GATE CMOS/74HCT NOR QUAD 2-INP
54 Backdating Information Appendix B
