WUG2690
802.11b/g Wireless LAN USB 2.0 Adapter
WIRELESS SPECIFICATION
Standard
IEEE 802.11b/g
Host Interface
USB 2.0
Antenna Connector
One SMA connector and one I-Pex connector
Frequency Range
2.412GHz ~ 2.4835GHz
Number of Selectable Channels
USA, Canada: 11 channels
Europe: 13 channels
Japan: 14 channels
Modulation Technique
Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
Orthogonal frequency division multiplexing(OFDM)
Security
64/128/256-bit WEP Encryption and Wi-Fi Protected Access, AES-CCM,
TKIP
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Output power
11g: 13 dBm
11b: 16 dBm
Data Rate
802.11g(54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6 Mbps)
802.11b(11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps)
Throughput
21.5Mbps @ 54Mbps
5.9Mbps @ 11Mbps
Sensitivity
-68 dBm@54Mbps
-85 dBm@11Mbps
