qos classifier modify

703

Procedure (Flow Classifier)

1

Enter the number of the classifier that you want to modify. The current

numbers are shown in braces { }.

2

To modify the name, enter the new name for the classifier.

The name that is associated with the classifier number that you specified

is shown in brackets.

Start and end

of TCP or UDP

destination

port range

For

flow

classifiers only,

start and end of the TCP

or UDP destination port

range.

Specify as small a range

as possible. The start

value determines the

end value.

0 – 65535 0 and

65535

(factory

defaults),

or current

values

Additional

filters

(address/port

patterns)

For

flow

classifiers only,

additional source,

destination, and port

information for this

classifier. Each set of

information counts

toward the classifier

limit.

■

y (yes)

■

n (no)

no (factory

default)

Custom

protocol type

(custom

nonflow

classifiers only)

For

nonflow

classifiers

with the custom

protocol type.

■

Ethertype

■

DSAP/SSAP

–

Custom

protocol

hexidecimal

value (custom

nonflow

classifiers only)

Hex values for

nonflow

classifiers with the

custom protocol type.

■

Ethertype hex value

of 0x0 – 0xffff

■

DSAP hex value of

0x0 – 0xff

■

SSAP hex value of

0x0 – 0xff

0x0

–

0x0

802.1p tag For

nonflow

classifiers

only, the IEEE 802.1p

tag value

■

Any combination of

priority tag values in

the range of 0 – 7

■

all

■

? (for a list of

selectable values)

Current

value, if

any

Prompt Description Possible Values [Default]
