3. Press p button, ensure iPod responds to the command correctly. If
not, remove receiver from iPod and repeat steps 2 and 3 until iPod
responds correctly.
You are now ready to wirelessly control your iPod with your watch!
TIPS:
•
Q will be visible on display in modes where iPod use is possible
(TIME, CHRONO, INTERVAL TIMER and TIMER modes).
• There will be a slight delay in the iPod's response to button presses
on the watch. This is normal.
• Fast-forward or reverse through the currently playing track is not
available, therefore holding U or u watch buttons has no effect.
• It is not possible to turn your iPod off by holding p button.
• The i-Control® watch is designed to operate up to a range of about
10 ft. (3 m). Range will be affected by watch and iPod battery voltage.
If range is greatly reduced even with iPod fully charged, it may be
necessary to replace watch battery. Refer to battery change instruc-
tions at the end of these instructions.
• Receiver is powered by iPod, therefore use of the i-Control system
will reduce time between charges for the iPod. Unplug receiver from
iPod when not using the i-Control system.
TIME/DATE/HOURLY CHIME
SETTING TIME AND DATE:
1. In TIME mode, press and hold STOP/RESET/SET. Time Zone flashes.
2. Press + or – to select Time Zone 1, 2 or 3.
3. Press NEXT to set hour. Digits flash.
4. Press + or – to change hour. Scroll through 12 hours to change to
AM/PM.
5. Press NEXT and + / – to set minutes.
6. Press NEXT and + / – to set seconds to zero.
7. Continue pattern to set day, month, date, year, 12-hour (AM/PM) or
24-hour military time format, MM.DD or DD.MM date format, turn
hourly Chime on/off, turn Beep on/off. If you select Beep on, beep will
sound every time you push a button except INDIGLO® button.
8. Press NEXT to set next Time Zone, following procedure above.
BASIC OPERATIONS
When setting, each button has a different function as indicated above.
Display indicates when button changes function.
IPOD CONTROL
GETTING STARTED WITH YOUR i-CONTROL® WATCH
Perform these steps each time you are attaching the receiver device to
your iPod to ensure reliable operation:
1. Press MODE until watch is in TIME mode. Q will be visible on display.
2. Plug receiver into iPod dock connector.
2
3
START/SPLIT
INDIGLO
®
BUTTON
STOP/RESET/SET
OR DONE (To save
changes and exit
setting)
MODE OR NEXT
(Proceed to next step)
VOLUME UP
OR Increase value.
Hold to increase rapidly
NEXT TRACK
OR Proceed to next step
VOLUME DOWN
OR Decrease value.
Hold to decrease rapidly
iPod® ICON
PREVIOUS TRACK
(Refer to Mode
descriptions for
operation)
PLAY/PAUSE
(Refer to Mode
descriptions for
operation)
VOLUME UP
NEXT TRACK
VOLUME DOWN
T0705-13_W240_EN_NA.qxd 5/17/07 2:05 PM Page 2
