25
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. If a part is miss-
ing, call toll-free 1-888-533-1333. See the back cover of this manual for information about ordering replace
-
ment parts.
1 1 Base
2
1 Frame
3 1 Upright
4 1 Upright Endcap
5 1 Console
6 1 Front Stabilizer
7 1 Rear Stabilizer
8 1 Left Handlebar
9 1 Right Handlebar
10 2 Handlebar Endcap
11 1 Left Upper Body Arm
12 1 Right Upper Body Arm
13 1 Left Pedal
14 1 Left Pedal Leg
15 1 Right Pedal
16 1 Right Pedal Leg
17 2 Upright Cover
18 1 Left Front Handlebar
Cover
19 1 Left Rear Handlebar
Cover
20 1 Right Front Handlebar
Cover
21 1 Right Rear Handlebar
Cover
22 1 Water Bottle Holder
23 2 Front Stabilizer Endcap
24 2 Rear Stabilizer Endcap
25 2 Wheel
26 1 Base Foot
27 2 Leveling Foot
28 1 Left Side Shield
29 1 Right Side Shield
30 6 Upper Body Bushing
31 4 Pedal Leg Cover
32 2 Pedal Leg Axle
33 4 Pedal Leg Bushing
34 1 Base Axle
35 2 Base Bushing
36 2 Crank Arm
37 2 Inner Crank Cover
38 2 Crank Hub
39 1 Pulley Spacer
40 1 Pulley
41 2 Crank Bushing Cover
4
2 4 Crank Bushing
43 2 Crank Bushing Sleeve
44 2 Crank Bearing Set
45 1 Crank
46 1 Crank Spacer
47 2 Crank Snap Ring
48 1 Upper Wire Harness
49 1 Lower Wire Harness
50 1 Reed Switch/Wire
51 1 Belt
52 1 Flywheel
53 1 “C” Magnet
54 1 Pillow Block
55 1 Magnet
56 1 Spring
57 1 Idler
58 1 Idler Bracket
59 1 Clamp
60 1 Reed Switch Bracket
61 1 Base Pin
62 2 Latch Bracket Spacer
63 2 Hairpin Cotter Pin
64 1 Latch Bracket
65 1 Pivot Bracket
66 2 Pivot Bracket Spacer
67 1 Frame Pin
68 1 Latch Button
69 1 Roll Pin
70 1 Motor
71 1 Resistance Cable Pulley
72 1 Resistance Cable Set
73 2 Foam Grip
74 1 Pivot Axle
75 2 Hub Cover
76 2 Outer Crank Cover
77 2 Flywheel Bracket
78 4 M8 x 41mm Button Bolt
79 7 M8 Jamnut
80 1 M8 x 69mm Button Bolt
81 4 M10 Nylon Locknut
82 2 M10 x 80mm Carriage
Bolt
83 2 M10 x 127mm Button
Screw
84 4 M8 x 23mm Button
S
crew
85 1 M6 x 10mm Button
Screw
86 2 Crank Screw
87 8 Hub Screw
88 10 M8 Washer
89 2 M10 x 60mm Button
Screw
90 3 M8 Split Washer
91 1 Flywheel Spacer
92 1 Flywheel Washer
93 1 Flywheel Snap Ring
94 4 Pillow Block Screw
95 1 Stop Screw
96 1 M8 x 35mm Screw
97 1 “E” Clip
98 4 Pulley Screw
99 2 Crank Washer
100 2 M4 x 25mm Screw
101 8 M4 x 16mm Round
Head Screw
102 4 Motor Washer
103 23 M4 x 16mm Screw
104 8 M4 x 14mm Screw
105 6 M4 x 32mm Round
Head Screw
106 2 M8 x 31mm Shoulder
Screw
107 4 M4 x 12mm Screw
108 2 M4 x 45mm Screw
109 2 Large Wave Washer
110 2 M8 Small Washer
111 2 Wave Washer
112 8 Star Washer
113 1 M10 Washer
114 1 M6 Nut
115 4 M8 x 23mm Shoulder
Screw
# 3 Allen Wrench
# 1 Grease
# 1 User’s Manual
K
ey
No. Qty. Description
K
ey
No. Qty. Description
K
ey
No. Qty. Description
PART LIST—Model No. 831.28544.2 R0606A
