To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual.
30
PART LIST—Model No. DTL52942 R0604A
1 2 Foot Rail Cover
2 1 Left Foot Rail
3 1 Left Front Endcap
4 2 Belt Guide
5 4 Belt Guide Screw
6 56 3/4” Screw
7 1 Console Frame
8 4 Cage Nut
9 1 Incline Wire
10 1 Warning Decal
11 2 Rear Platform Bolt
12
1 Latch Cover
13 1 Pulse Bar Plate (Left)
14 1 Pulse Bar Plate (Right)
15 2 Isolator
16 4 Platform Screw
17 2 Platform Pivot Bolt
18 1 Magnet
19 2 Caution Decal
20 1 Motor Pivot Bolt
21 7 Wheel Nut
22 2 Frame Spacer
23 1 Reed Switch Clip
24 1 Reed Switch
25 1 Reed Switch Screw
26 1 Lift Frame
27 1 Motor Tension Nut
28 1 Motor
29 1 Pulley/Flywheel/Fan
30 1 Motor Belt
31* 1 Motor Assembly
32
1
Motor Tension Bolt
33 5 Motor Tension Washer/
Lift Pivot Washer
34
1
Motor Star Washer
35
2
Motor Bracket Bolt
36 7 Small Screw
37
1 Ground Wire
38
1
Transformer
39 1 Hood
40 1 Controller
41
1
Power Cord
42 1 iFIT.com Wire Nut
43 1 iFIT.com Wire
44
1
Power Cord Grommet
45 2 Static Decal
46 1 Reset/Off Switch
47 11 3/4” Tek Screw
48
1 Belly Pan
49 1 Photo Switch Wire
50 1 Filter Wire
51 1 Right Front Endcap
52 1 Walking Belt
53 1 Walking Platform
54 1 Frame
55 2 Platform Nut
56 1 Right Foot Rail
57 1 Rear Roller
58 2 Rear Foot
59 1 Allen Wrench
60 2 Rear Roller Adj. Bolt
61
2 Rear Roller Washer
62 1 Right Rear Endcap
63 1 Photo Switch
64 1 Left Rear Endcap
65 2 Small Endcap Screw
66 2 Endcap Washer
67 4 Front Endcap Screw
68 4 Pulse Bar Screw
69 2 Isolator Plate
70 1 Right Cup Holder (Bottom)
71 4 1/4” x 1” Bolt
72 1 Right Cup Holder (Top)
73 1 Left Cup Holder (Bottom)
74* 1 Latch Assembly
75 1 Latch Housing
76 1 Left Cup Holder (Top)
77 1 Photo Switch Bolt
78 1 Jack
79 1 Book Holder
80 6 Screw
81
4
Isolator Plate Screw
82 1 Incline Motor
83 1 Wire Harness
84
1
Isolator Housing
85
1
Optic Disk
86 1 Right Foot Rail
87
1 Fan
88
1
Console
89 1 Fan Housing
90 2 Center Isolator
91
1
Key/Clip
92 4 1/4” Star Washer
93 2 Isolator Cap
94
1
Access Door
95 1 Console Back
96 1 Tie Holder
97 1 Releasable Tie
98
8 Plastic Tie
99 2 Base Endcap
Key No. Qty. Description Key No. Qty. Description
