12
Turn on the console.
Note: The console requires four “D” batteries (not
included). If you have not installed batteries, refer
to step 5 on page 6 and install batteries.
To turn on the console, press the On/Reset button
or begin pedaling.
Select the manual mode.
Each time the
console is
turned on, the
manual mode
will be select-
ed. If a Smart
program, a
Heart Rate pro-
gram, or the iFIT.com mode has been selected,
select the manual mode by pressing the Program
button repeatedly until the upper right corner of
the display is blank.
Begin exercising and adjust the resistance of
the elliptical crosstrainer.
As you exercise, adjust the resistance of the
elliptical crosstrainer as desired by pressing the +
and – buttons. There are ten resistance levels;
level 10 is the most challenging. Note: After the
buttons are pressed, it will take a few seconds for
the selected setting to be reached.
Follow your progress with the feedback modes
and the left pace indicator.
When the con-
sole is turned
on, the scan
mode will be
selected. As
you exercise,
the display will
show your cur-
rent speed, the elapsed time, the distance that
you have pedaled, the current resistance level,
and the approximate numbers of calories and fat
calories you have burned. In addition, your heart
rate will be shown when you use the handgrip
pulse sensor (refer to step 5 below). Note: Each
time the resistance level changes, the console
will show the resistance level for six seconds. In
addition, when a Smart program or a Heart Rate
program is selected, the display will show the
time remaining in the program instead of the
elapsed time.
If desired, you can select a single feedback mode
for continuous display. Press the Display Mode
button repeatedly until only the MPH (or Km/H),
Time, Miles (or Kms), Resist., Cals., or Fat Cals.
indicator appears in the display. Make sure that
the Scan indicator does not appear.
In addition, the left pace indicator will appear in the
display to show your exercise pace. As you
increase or decrease your pace, additional bars
will appear or disappear in the pace indicator.
Measure your heart rate if desired.
Note: If there
are thin sheets
of plastic on
the metal con-
tacts on the
handgrip pulse
sensor, peel off
the plastic.
To use the handgrip pulse sensor, place your
hands on the metal contacts. Your palms must be
on the upper contacts and your fingers must be
touching the lower contacts. Avoid moving your
hands. When your pulse is detected, the heart-
shaped indicator in the display will flash each
time your heart beats. After a moment, two dash-
es (– –) will appear and then your heart rate will
be shown.
For the most accurate heart rate reading, continue
to hold the handgrips for about 15 seconds. Note:
When you first hold the handgrips, the display will
show your heart rate continuously for 15 sec-
onds. The display will then show your heart rate
along with the other feedback modes.
When you are finished exercising, the console
will automatically turn off.
If the pedals are not moved and the console but-
tons are not pressed for a few minutes, the con-
sole will automatically turn off to conserve
the batteries.
6
5
4
3
2
1
HOW TO USE THE MANUAL MODE
This corner
should be blank
Metal
Contacts
