Owner’s Manual: Display Console 19
More Information about the
Center Display
SmartRate—displays your heart rate as a blinking bar
which indicates the zone you are in when you grasp both
touch-sensitive grips. A heart icon blinks in the center
display when a heart rate is being detected. Refer to Using
SmartRate.
PROGRAM PROFILE—In most programs, the CrossRamp
setting affects the column height in the program profile as
shown in Diagram 7. The profile raises or lowers according
to which arrow key is pressed.
Diagram 7: Column height in the program profile
USER—displays the current user. Refer to User
Identification.
PROGRAM—displays the current program selection. Refer
to Programs.
CROSSRAMP
STRIDES/min
DISTANCE
RESISTANCE
HEART RATE
CALORIES
TIME
USER
PEAK
CARDIO
FATBURN
WARMUP
HIGH
Smart Rate
130
888.8888.8 8.88:88
Column height
CrossRamp settings
