Page 6 For technical questions, please call 1‑800‑444‑3353. SKU 67802
Instructions
Read the ENTIRE
IMPORTANT SAFETY
INFORMATION section
at the beginning of this
document before set up
or use of this product.
Distance Measurement
1. Place measurement base against
object to measure from.
2. Point at target and press READ.
Laser will show only while
READ is pressed.
3. For a continuous measurement,
press and hold READ while moving.
4. Each measurement erases
the previous one.
5. Measured distance is displayed as
Current Result at top of the Display.
6. Unit automatically turns off after
30 seconds of inactivity.
7. TIPS:
• There must be no objects in
the measurement path.
• For accuracy, choose a target
that is at and large with hard
surfaces or put a piece of
cardboard in front of the target.
• The meter will only measure up
to glass, but not through it.
Addition
Note: Addition can be used for
distance, area, or volume
measurements.
However, those measurements
are different units (for example,
feet, square feet, and cubic feet)
and cannot be added together.
1. Take rst measurement
as explained under
“Distance Measurement”.
2. Press + / = button.
A + will appear above and to
the left of the Current Result.
3. Take another measurement
as explained under
“Distance Measurement”.
4. Press + / = button again.
Combined measurement is
displayed as Total Result at
the bottom of the display.
5. Steps 3 and 4 can be repeated
to add more measurements.
