COMMERCIAL PRODUCTS DIVISION
Precor Handrail Option Kit
Fits Precor C944, C942, C940, M9.45, M9.41s Treadmills
Thank you for purchasing the Precor Handrail Option Kit. Each kit comes
complete with all the hardware required to install a handrail on one side of the
treadmill. If you wish handrails on both sides of the treadmill, you must order two
(2) option kits. When you receive the Handrail Option kit, check its contents with
the list below:
Note: If you purchase both handrails, check the contents of both kits with the list
below:
Handrail Option Kit Contents
One handrail
One upper end clamp
One upper center clamp
Three large bolts (two 5/16 - 18 x 2.5 and one 1/4 - 20 x 2.5)
One star washer
One nut plate
One lower clamp
One 5/32" hex key
One 3/16" hex key
Note: To assemble the handrail(s), you will need a Phillips head screwdriver.
ASSEMBLY INSTRUCTIONS
The assembly of each handrail is the same on opposite sides of the treadmill. To
properly install the handrail(s) on your unit, take the following steps:
CAUTION: Turn OFF the unit and unplug it from the power source before
installing the handrail(s).
